Quality Assurance
Quality Policy
Technology Innovation, Superior Quality, Customer Comes First, Perfect Service
Quality Objective
Zero Defect Operation
10PPM Quality Level
100% on Time Delivery
Quality System
Reliability Testing Flow
Reliability Testing
| Test Item | Test Condition | Quality Level Criteria | |
| 1. | SOLDER RESISTANCE | TEMPERATURE OF SOLDER POT=260℃+5℃/-0℃ DURATION TIME FOR DIPPING IN SOLDER = 10+/-1SEC | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 2. | Solderability | TEMPERATURE OF SOLDER POT = 230℃+/-5℃ | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 3. | HTIR | Ta = 100℃/ 125℃150℃/175℃ | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 4. | HTRB | Ta = 150℃+ /-5℃ ( SRⅡ) VR = 80% RATED TESTING TIME：1000HRS | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 5. | PCT | Ta=121℃ P = 15PSI TESTING TIME：96HRS | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 6. | OP Life | Ta=25℃ Power 60Hz, I = Rated Io TESTING TIME：1000HRS | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 7. | Forward Surge | SINE WAVE 60Hz IFSM PER CUSTOMER SPEC TESTING TIME：8.3 ms, T=1 CYCLE | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 8. | Thermal Fatigue | ON =5 MIN. FOR RATED Io OFF=5 MIN. FOR Ta TESTING TIME：300CYCLES | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 9. | Temperature Cycling | Ta=-65℃ to + 175℃ DWELLED FOR 30 MIN. AND TRANSFERED FOR 5 MIN. NUMBER OF CYCLES：10CYCLES | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
| 10. | Steam Aging | Ta=98~100℃ TESTING TIME：8HRS | S.S. = 22 LTPD 10 ACCEPT FOR 0 FAILURE ONLY |
